Led Recessed Mini Panels

Order Code: DALMINO 4821 6000 K / WHITE
Order Code: DALMINO 4822 4500 K / DAYWHITE
Order Code: DALMINO 4823 3000 K / WARMWHITE

Wattage: 8W
EQ.Watts: 24 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 120 °
Luminous Flux: 800 lm
Shape: Round
Material: Aluminum (PKW)
Dimensions:
Diameter - 145 mm
Height - 20 mm
Cutting Size: Ø 125 mm
Driver: Non-dimmable 8036
Driver: Dimmable 8058

Order Code: DALMINO 4827 6000 K / WHITE
Order Code: DALMINO 4828 4500 K / DAYWHITE
Order Code: DALMINO 4829 3000 K / WARMWHITE

Wattage: 15W
EQ.Watts: 45 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 120 °
Luminous Flux: 1500 lm
Shape: Round
Material: Aluminum (PKW)
Dimensions:
Diameter - 180 mm
Height - 20 mm
Cutting Size: Ø 160 mm
Driver: Non-dimmable 8037
Driver: Dimmable 8059

Order Code: DALMINO 4833 6000 K / WHITE
Order Code: DALMINO 4834 4500 K / DAYWHITE
Order Code: DALMINO 4835 3000 K / WARMWHITE

Wattage: 22W
EQ.Watts: 70 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 120 °
Luminous Flux: 2200 lm
Shape: Round
Material: Aluminum (PKW)
Dimensions:
Diameter - 240 mm
Height - 20 mm
Cutting Size: Ø 220 mm
Driver: Non-dimmable 8038
Driver: Dimmable 8060

Order Code: DALMINO 4850 6000 K / WHITE
Order Code: DALMINO 4849 4500 K / DAYWHITE
Order Code: DALMINO 4848 3000 K / WARMWHITE

Wattage: 28W
EQ.Watts: 84 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 120 °
Luminous Flux: 2800 lm
Shape: Round
Material: Aluminum (PKW)
Dimensions:
Diameter - 260 mm
Height - 20 mm
Cutting Size: Ø 220 mm
Driver: Non-dimmable 8065
Driver: Dimmable 8059

Order Code: DALMINO 4818 6000 K / WHITE
Order Code: DALMINO 4819 4500 K / DAYWHITE
Order Code: DALMINO 4820 3000 K / WARMWHITE

Wattage: 8W
EQ.Watts: 24 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 120 °
Luminous Flux: 800 lm
Shape: Round
Material: Aluminum (PKW)
Dimensions:
Diameter - 120 x 120 mm
Height - 20 mm
Cutting Size: 105 x 105 mm
Driver: Non-dimmable 8036
Driver: Dimmable 8058

Order Code: DALMINO 4824 6000 K / WHITE
Order Code: DALMINO 4825 4500 K / DAYWHITE
Order Code: DALMINO 4826 3000 K / WARMWHITE

Wattage: 15W
EQ.Watts: 45 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 120 °
Luminous Flux: 1500 lm
Shape: Round
Material: Aluminum (PKW)
Dimensions:
Diameter - 160 x 160 mm
Height - 20 mm
Cutting Size: 140 x 140 mm
Driver: Non-dimmable 8037
Driver: Dimmable 8059

Order Code: DALMINO 4830 6000 K / WHITE
Order Code: DALMINO 4831 4500 K / DAYWHITE
Order Code: DALMINO 4832 3000 K / WARMWHITE

Wattage: 22W
EQ.Watts: 70 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 120 °
Luminous Flux: 2200 lm
Shape: Round
Material: Aluminum (PKW)
Dimensions:
Diameter - 220 x 220 mm
Height - 20 mm
Cutting Size: 195 x 195 mm
Driver: Non-dimmable 8038
Driver: Dimmable 8060

Order Code: DALMINO 4933 6000 K / WHITE
Order Code: DALMINO 4932 4500 K / DAYWHITE
Order Code: DALMINO 4931 3000 K / WARMWHITE

Wattage: 8W
EQ.Watts: 40 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 110 °
Luminous Flux: 560 lm
Shape: Round
Material: Die Cast Aluminum
Dimensions:
Diameter - 100 mm
Height - 27 mm
Cutting Size: Ø 90 mm

Order Code: DALMINO 4936 6000 K / WHITE
Order Code: DALMINO 4935 4500 K / DAYWHITE
Order Code: DALMINO 4934 3000 K / WARMWHITE

Wattage: 15W
EQ.Watts: 100 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 120 °
Luminous Flux: 150 lm
Shape: Round
Material: Die Cast Aluminum
Dimensions:
Diameter - 145 mm
Height - 27 mm
Cutting Size: Ø 135 mm

Order Code: DALMINO 4939 6000 K / WHITE
Order Code: DALMINO 4938 4500 K / DAYWHITE
Order Code: DALMINO 4937 3000 K / WARMWHITE

Wattage: 22W
EQ.Watts: 120 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 110 °
Luminous Flux: 2200 lm
Shape: Round
Material: Die Cast Aluminum
Dimensions:
Diameter - 170 mm
Height - 27 mm
Cutting Size: Ø 160 mm

Order Code: DALMINO 4936 6000 K / WHITE
Order Code: DALMINO 4935 4500 K / DAYWHITE
Order Code: DALMINO 4934 3000 K / WARMWHITE

Wattage: 29W
EQ.Watts: 200 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 110 °
Luminous Flux: 2800 lm
Shape: Round
Material: Die Cast Aluminum
Dimensions:
Diameter - 200 mm
Height - 27 mm
Cutting Size: Ø 185 mm

Order Code: DALMINO 4945 6000 K / WHITE
Order Code: DALMINO 4944 4500 K / DAYWHITE
Order Code: DALMINO 4943 3000 K / WARMWHITE

Wattage: 8W
EQ.Watts: 40 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 110 °
Luminous Flux: 560 lm
Shape: Round
Material: Die Cast Aluminum
Dimensions:
Diameter - 95 x 95 mm
Height - 27 mm
Cutting Size: 85 x 85 mm

Order Code: DALMINO 4948 6000 K / WHITE
Order Code: DALMINO 4947 4500 K / DAYWHITE
Order Code: DALMINO 4946 3000 K / WARMWHITE

Wattage: 15W
EQ.Watts: 100 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 110 °
Luminous Flux: 1500 lm
Shape: Round
Material: Die Cast Aluminum
Dimensions:
Diameter - 145 x 145 mm
Height - 27 mm
Cutting Size: 135 x 135 mm

Order Code: DALMINO 4798 6000 K / WHITE
Order Code: DALMINO 4797 4500 K / DAYWHITE
Order Code: DALMINO 4949 3000 K / WARMWHITE

Wattage: 22W
EQ.Watts: 120 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 110 °
Luminous Flux: 2200 lm
Shape: Round
Material: Die Cast Aluminum
Dimensions:
Diameter - 170 x 170 mm
Height - 27 mm
Cutting Size: 160 x 160 mm

Order Code: DALMINO 4954 6000 K / WHITE
Order Code: DALMINO 4953 4500 K / DAYWHITE
Order Code: DALMINO 4952 3000 K / WARMWHITE

Wattage: 29W
EQ.Watts: 200 W
Voltage: AC100-240V
LED Type: SMD
CRI: >80
PF: >0.9
Beam Angle: 110 °
Luminous Flux: 2800 lm
Shape: Round
Material: Die Cast Aluminum
Dimensions:
Diameter - 200 x 200 mm
Height - 27 mm
Cutting Size: 185 x 185 mm

Order Code: DALMINO 4856 6000 K / WHITE
Order Code: DALMINO 4855 4500 K / DAYWHITE
Order Code: DALMINO 4854 3000 K / WARMWHITE

Wattage: 6W
Voltage: AC100-240V
Led Chip: SMD
CRI: >75
PF: >0.9
LED Type: COB Reflector, Epistar Chip
Beam Angle: 120 °
Luminous Flux: 400 lm
Material: PKW
Dimensions:
Diameter - 120 mm
Height - 25 mm
Mounting diameter - 105 mm

Order Code: DALMINO 4859 6000 K / WHITE
Order Code: DALMINO 4858 4500 K / DAYWHITE
Order Code: DALMINO 4857 3000 K / WARMWHITE

Wattage: 12W
Voltage: AC100-240V
Led Chip: SMD
CRI: >75
PF: >0.9
LED Type: COB Reflector, Epistar Chip
Beam Angle: 120 °
Luminous Flux: 900 lm
Material: PKW
Dimensions:
Diameter - 170 mm
Height - 25 mm
Mounting diameter - 155 mm

Order Code: DALMINO 4862 6000 K / WHITE
Order Code: DALMINO 4861 4500 K / DAYWHITE
Order Code: DALMINO 4860 3000 K / WARMWHITE

Wattage: 18W
Voltage: AC100-240V
Led Chip: SMD
CRI: >75
PF: >0.9
LED Type: COB Reflector, Epistar Chip
Beam Angle: 120 °
Luminous Flux: 1350 lm
Material: PKW
Dimensions:
Diameter - 225 mm
Height - 25 mm
Mounting diameter - 205 mm

Order Code: DALMINO 4865 6000 K / WHITE
Order Code: DALMINO 4864 4500 K / DAYWHITE
Order Code: DALMINO 4863 3000 K / WARMWHITE

Wattage: 6W
Voltage: AC100-240V
Led Chip: SMD
CRI: >75
PF: >0.9
LED Type: COB Reflector, Epistar Chip
Beam Angle: 120 °
Luminous Flux: 400 lm
Material: PKW
Dimensions:
Diameter - 120 x 120 mm
Height - 25 mm
Mounting diameter - 105 x 105 mm

Order Code: DALMINO 4868 6000 K / WHITE
Order Code: DALMINO 4867 4500 K / DAYWHITE
Order Code: DALMINO 4866 3000 K / WARMWHITE

Wattage: 12W
Voltage: AC100-240V
Led Chip: SMD
CRI: >75
PF: >0.9
LED Type: COB Reflector, Epistar Chip
Beam Angle: 120 °
Luminous Flux: 900 lm
Material: PKW
Dimensions:
Diameter - 170 x 170 mm
Height - 25 mm
Mounting diameter - 155 x 155 mm

Order Code: DALMINO 4871 6000 K / WHITE
Order Code: DALMINO 4870 4500 K / DAYWHITE
Order Code: DALMINO 4869 3000 K / WARMWHITE

Wattage: 18W
Voltage: AC100-240V
Led Chip: SMD
CRI: >75
PF: >0.9
LED Type: COB Reflector, Epistar Chip
Beam Angle: 120 °
Luminous Flux: 1350 lm
Material: PKW
Dimensions:
Diameter - 225 x 225 mm
Height - 25 mm
Mounting diameter - 205 x 205 mm
